Within two minutes, push down the key on the second plug.The power-supply LED will flash slowly (0.5 seconds on/0.5 seconds off). Push down the (reset/simple connect) key on the first Powerline plug for two seconds.Once they have been successfully connected, you can put them in the desired location. The easiest way is to plug them in next to each other in the same place.
Plug all the Powerlines into the power socket. To connect them with each other, follow the procedure set out below. The Powerline plug switches to stand-by mode (energy saving function) when it is not connected to a device through an Ethernet cable for 15 minutes.īy default, the Powerlan NS-6701 plugs are not connected. Power socket Connecting the Powerlan NS-6701 plugs Push down for 10 seconds to randomized the network password. Push down for 5 seconds to restore the factory settings. Push down for two seconds to start the connection sequence. Ethernet connection X2:įor connection to an external device through an Ethernet cable. The LED flashes when data is being transferred. On: successful connection with another device through an Ethernet cable. Safety instructionsįor your own safety, make sure you read and follow all warning notices and instructions. Some electrical equipment, such as microwave ovens, vacuum cleaners, and old laptop/mobile phone chargers, will generate background noise on the mains network during operation. In some cases, there will be no communication at all. The quality of the Powerline connection will be dramatically impaired if the devices are connected to different phases. multiphase voltage: some houses have three-phase electricity. The connection quality will be impaired by:
Ideally, the maximum electrical cable length between two Powerline devices should be no more than 200 metres. To connect them, follow the procedure given in Chapter 6. By default, the Powerlan NS-6701 plugs are not connected.
Powerlan NS-6701 plugs can be used to establish a network connection between your modem, PC, set-top Box, games console, etc.
